The AMC B25A20AC, B30A40AC, B40A40AC, B60A40AC, and B100A400AC provide dipswitch settings for various amplifier configurations. It is recommended that you start with the following settings. You may determine other settings that are better for your particular situation, but these settings should get you started.
Our current model supported AMC B30A40AC Amplifier Setup Guide
The B30A40AC and B60A40AC provide dipswitch settings for various amplifier configurations using two six position dipswitches. It is recommended that you start with the following settings. You may determine other settings that are better for your particular situation, but these settings should get you started.
AMC B25A20AC, B40A40AC, and B100A40AC Dipswitch Setup
AMC B100A400AC Dipswitch Setup
